Product Description
The WELDBEND 105-122-040-000 is a weld neck flange used in piping systems. This flange is a raised face type designed for high-pressure applications. It has a nominal size of four inches. It is constructed from forged carbon steel.
- Nominal size: 4 inches
- Pressure rating: 285 psig
- Thickness: 0.88 inches
Product Highlights
This flange is suitable for various pipe fittings and is ideal for industries requiring resilient connections under pressure.
Product Information
Standard Information
- Manufacturer: WELDBEND CORP
- Type: Raised Face
Technical Specifications
- Nominal Size: 4 in
- Inside Diameter: 4.03 in
- Outside Diameter: 9 in
- Bore Size: XS
- Thickness: 0.88 in
- Hub Diameter: 5.31 in
- Length Through Hub: 2.94 in
- Bolt Circle Diameter: 7-1/2 in
- Number of Bolt Holes: 8
- Pressure Class: 150 lb
- Pressure Rating: 285 psig
- Temperature Rating: -20 to 100 deg F
- Material: Forged Carbon Steel
