Product Description
The Victaulic FireLock Style 652 with MPN FB64652C00 is a concentric reducer. This fitting facilitates a change in pipe size from two inches to one and one-quarter inches in copper piping systems. It is designed to connect different diameter pipes efficiently.
- Constructed from high-quality wrought copper.
- Compatible with style 607 rigid, style 606 rigid couplings, and style 641 flange adapters.
- Pressure rated up to three hundred psi.
Product Highlights
This fitting supports full-flow in copper systems making it effective for plumbing applications.
Product Information
Standard Information
- Brand: Victaulic
- MPN: FB64652C00
Technical Specifications
- Nominal Size: 2 x 1-1/4 inches
- Connection Type: Grooved x Cup
- Material: Wrought Copper
- Standards: ASTM B75, ASTM B152, UL, ULC Listed, FM Approved
- Maximum Pressure: 300 psi
- Outside Diameter: 2-1/8 x 1-3/8 inches
- Length: 3 inches
- Other Dimension: 0.97 inches cup
