Product Description
TB Woods 744B is a classical sheave designed for A-B belt sections. This product features a four-groove configuration and an outside diameter of seven and three-fourths inches. Constructed from cast iron, it is built for reliable performance in mechanical power transmission applications.
- High durability from cast iron construction.
- Designed for classical V-belts including A and B sections.
- Compatible with QD-type bushings.
Product Highlights
This sheave is suitable for various applications, making it a versatile choice for technicians and engineers. Ensure optimal performance by pairing it with appropriate belts and bushings.
Product Information
Standard Information
- Brand: TB Woods
- MPN: 744B
Technical Specifications
- Outside Diameter: 7.75 inches
- Number of Grooves: 4
- Face Width: 3.25 inches
- Bushing Series: SK
- Pitch Diameter: 7 inches (A), 7.4 inches (B)
- Bushing Bore Range: 1/2 to 2-5/8 inches
- Length Through Bore: 1.875 inches
- Weight: 13.9 lbs
