Product Description
The Square D LS1D30 is a fuseholder designed for a thirty ampere current rating. It features screw clamp terminals and is suitable for use with Class CC or KTK-R fuses. This product’s mounting is compatible with standard DIN rail configurations, making it efficient for installation in motor control applications.
- UL 508 and CSA C22.2 approved.
- Voltage rating of six hundred ninety volts.
- Compatible with three-pole setups.
Product Highlights
The Square D LS1D30 is ideal for protecting circuits in industrial and commercial settings. Its screw clamp terminal type ensures secure connections for wire sizes ranging from sixteen to eight AWG, making it versatile for various electrical applications.
Product Information
Standard Information
- Manufacturer: Square D Co.
- UPC: 38911027308
Technical Specifications
- Catalog Number: LS1D30
- Fuse Type: 10.3 mm x 38 mm Class CC/KTK-R
- Fuse Current Rating: 30 Ampere
- Voltage Rating: 690 V
- Number of Poles: 3
- Approval: UL 508, CSA C22.2
- Operating Temperature: -58 to 158 Deg F
- Line Wire Size: (2) 16 to (2) 8 AWG Solid
- Load Wire Size: (2) 16 to (2) 8 AWG Solid
