Product Description
Schneider Electric VS-7323-804-4-04 is a globe valve actuator assembly designed for automatic control applications. This valve features a body size of one-half inches and operates as a three-way diverting valve. It provides efficient fluid control for various heating and cooling systems.
- Body Size: 1/2 in
- Configuration: 3-Way Diverting
- Type: Globe
Product Highlights
This valve actuator assembly utilizes a proportional control signal and has a close-off pressure rating of 250 PSI. It delivers a flow coefficient of 4.4 cv, suitable for precise flow management.
Product Information
Standard Information
- Brand: Schneider Electric
- Country of Origin: US
- Manufacturer: Schneider Electric
Technical Specifications
- Body Material: Brass
- Control Signal Range: 2 to 10 VDC
- Power Input Voltage: 24 VAC/VDC
- Force: 105 lbf
- Protection Rating: NEMA 2
- Operating Fluid Temperature: -7 to 138 °C
- Ambient Air Temperature For Operation: -30 to 60 °C
- Relative Humidity: 5 to 95 % non-condensing
