Product Description
Schneider Electric VS-2313-536-9-30 is a valve assembly designed for mixing applications. It features a body size of one inch and is a three-way mixing type ball valve with NPT connections. This valve is made of forged brass and operates efficiently under a maximum close-off pressure of fifty PSI.
- Body Size: 1 inch
- Configuration: 3-Way Mixing
- Torque: 35 in-lb
Product Highlights
This valve assembly provides reliable operation for your mixing needs. The electric actuator supports proportional control signals, facilitating accurate flow management. The product is rated for NEMA 2 protection, making it suitable for various environments.
Product Information
Standard Information
- Brand: Schneider Electric
- MPN: VS-2313-536-9-30
Technical Specifications
- Actuator Type: Electric
- Flow Coefficient: 22.3 cv
- Control Signal Range: 2 to 10 VDC, 4 to 20 mA
- Power Input Voltage: 24 VAC, 22 to 30 VDC
- Installation Configuration: Normally Open
- Material Trim: Brass
- Operating Fluid Temperature: -7 to 121 °C
- Relative Humidity: 5-95 % non-condensing
