Product Description
The Schneider Electric VS-2313-505-9-44 is a valve actuator assembly designed for effective control in heating, ventilation, and air conditioning systems. This electric actuator features a compact design and is compatible with various valve setups.
- Body size of one and one-quarter inches
- Electric actuator with proportional control signal
- Constructed with brass for durability
Product Highlights
This valve actuator assembly is suitable for non-steam applications with precise control over flow and pressure.
Product Information
Standard Information
- Brand: Schneider Electric
- Country of Origin: US
Technical Specifications
- Valve Type: Ball
- Connection Type: NPT
- Flow Coefficient: 12.7 cv
- Close-Off Pressure: 40 PSI
- Power Input Voltage: 24 VAC
- Torque: 35 in-lb
- Control Signal Range: 0 to 10 VDC
- Operating Fluid Temperature: -7 to 121 °C
- Protection Rating: NEMA 2
- Relative Humidity: 5-95% non-condensing
- Actuator Type: Electric, rotary
- Electrical Insulation Class: Class II
- Material: Forged brass and polymer housing
