Product Description
Schneider Electric VS-2253-536-9-61 is a ball valve assembly designed for reliable fluid control. This two-inch valve features a stainless steel body and is suitable for various applications.
- Electric actuator for remote operation
- Flow coefficient of 41.7 cv
- Close-off pressure rating of 70 PSI
Product Highlights
This valve assembly offers a proportional control signal and is equipped with a spring return for fail-safe operation. It is suitable for use in multiple environments, ensuring high performance and reliability.
Product Information
Standard Information
- Brand: Schneider Electric
- Country of Origin: US
Technical Specifications
- Body Size: 2 in
- Configuration: 2-Way
- Type: Ball
- Connection: NPT
- Material Trim: Stainless Steel
- Flow Coefficient: 41.7 cv
- Close-Off Pressure: 70 PSI
- Actuator Type: Electric
- Control Signal: Proportional
- Voltage Input: 24 VAC or 22 to 30 VDC
- Torque: 35 in-lb
- Mechanical Movement: Rotary
- Protection Rating: NEMA 2
- Ambient Temperature Range: -30-60 °C
- Relative Humidity: 5-95 % non-condensing
- Power Consumption: 5.6 VA AC
