Product Description
The Schneider Electric VK-7283-303-4-08 is a globe valve assembly designed for precise flow control in various applications. This valve features a body size of one inch and operates as a two-way globe valve. It connects via NPT for easy installation.
- Actuator Type: Pneumatic
- Flow Coefficient: 12 cv
- Close-Off Pressure: 60 PSI
Product Highlights
This valve is built for durability and efficiency with stainless steel materials and a linear mechanical movement. It is suitable for a variety of industrial applications, ensuring reliable operation.
Product Information
Standard Information
- Brand: Schneider Electric
- MPN: VK-7283-303-4-08
Technical Specifications
- Configuration: 2-Way
- Body Pattern: Straightway
- Stem Flow Action: Stem up A closed
- Material Trim: Stainless Steel
- Control Signal: 2-Position (On/Off), Proportional
- Control Spring Range: 10 to 13 PSIG
- Mechanical Movement: Linear
- Protection Rating: NEMA 1
- Seating Seal Material: Port A: Stainless Steel 316
- Ambient Air Temperature For Operation: -28.8 to 104.4 °C
- Ambient Air Temperature For Storage: -40 to 104.4 °C
- Diaphragm Effective Area: 11 in²
