Product Description
The Panduit PV14-P47-C is a pin terminal designed for use with 16 to 14 AWG wires. This vinyl insulated pin terminal ensures a secure electrical connection and is constructed to prevent wire damage during installation. It measures .49 inches in pin length and features a solid pin design that protects the wire from over-tightening.
- Vinyl insulation for effective protection
- UL rated up to 600 volts
- Brazed seam protects barrel from splitting
Product Highlights
Ideal for pin-type terminal blocks, this Panduit terminal supports reliable connections in various applications.
Product Information
Standard Information
- Manufacturer: Panduit
- Part Number: PV14-P47-C
Technical Specifications
- Voltage Rating: 600 VAC
- Temperature Rating: 221 Degrees Fahrenheit (105 Degrees Celsius)
- Wire Size: 16 – 14 AWG
- Pin Length: .49 inches
- Pin Diameter: .07 inches
- Material: Copper
- Finish: Tin-Plated
- Standards: UL486A/B
