Product Description
The Milwaukee Valve 502-34 is a bronze globe valve with a nominal size of three-fourths of an inch. It features a female NPT (FNPT) end style suitable for plumbing and heating applications. This valve is constructed to handle pressures up to 200 psi. Its handwheel actuator allows for easy manual operation. This valve is designed for general service and conforms to MSS SP-80 standards.
- Material: Bronze
- Pressure Class: 125 lb to 200 lb
- Temperature: Rated up to 406 degrees Fahrenheit
Product Highlights
This globe valve is ideal for non-potable applications. It is built with a threaded bonnet and includes a bronze disc and trim.
Product Information
Standard Information
- Brand: Milwaukee Valve
- MPN: 502-34
Technical Specifications
- Actuator Type: Handwheel
- Body Material: Bronze
- End Style: FNPT
- Pressure Rating: 200 psi
- Nominal Size: 3/4 in
- Temperature Rating: 406 degrees Fahrenheit
- Inlet to Outlet Length: 2.56 inches
- Top to Inlet Center: 3.94 inches
- Hand Wheel Diameter: 2-1/2 inches
- Standards/Approvals: ASTM B62 Body, ASTM B16 Stem, MSS SP-80
