Product Description
The Milbank U8213-XL-KK-BLG is a meter socket designed for use in residential and commercial buildings. This ringless model features four terminal jaws and is rated for a maximum amperage of 100 amps. The installation allows for overhead or underground cable entry. The unit measures four and a half inches deep, twenty-eight and a half inches wide, and sixteen inches high.
- Made from G90 galvanized steel with a powder coat finish.
- UL Listed for safety and reliable operation.
- Includes knockout options for flexible installation.
Product Highlights
This meter socket is ideal for applications requiring a reliable power distribution solution. It supports various wires and is built for durability.
Product Information
Standard Information
- Brand: Milbank
- Country of Origin: United States
Technical Specifications
- Catalog Number: U8213-XL-KK-BLG
- Amperage Rating: 100 Amps
- Voltage Rating: 300 Volts AC
- Dimensions: 4.5L x 28.5W x 16H Inches
- Enclosure Type: NEMA 3R
- Material: G90 Galvanized Steel
- Frequency Rating: 60 Hz
- Phase: 1
- Number of Jaws: 4
- Knockouts: (1) 2 Inch, (2) 2 Inch, (3) 2 Inch, (4) 3 Inch, (5) 1/4 Inch, (5) 1/2 Inch
