Product Description
Martin 35BS133/4 is a bored-to-size type BS single pitch roller chain sprocket. This sprocket features a three-fourths inch bore diameter, an outside diameter of 1.746 inches, and is designed for use with #35 chain. It has 13 teeth and operates with a pitch of three-eighths inch. This sprocket is constructed from steel for durability.
- Includes keyway on the center line of the tooth
- Finished bore ready for use
- Non-hardened teeth for reduced wear
Product Highlights
This sprocket is suitable for various applications requiring precise alignment and minimal runout. Ideal for rotary power transmission systems.
Product Information
Standard Information
- Brand: Martin Sprocket & Gear
- Manufacturer Part Number: 35BS133/4
Technical Specifications
- Bore Diameter: 3/4 in
- Chain Size: #35
- Hub Diameter: 1-1/4 in
- Includes: (2) Setscrews
- Keyway Size: 3/16 x 3/32 in
- Length Through Bore: 3/4 in
- Material: Steel
- Number of Teeth: 13
- Pitch: 3/8 in
- Pitch Diameter: 1.567 in
- Screw Size: 1/4-20 x 1/4 in
- Standards: PROP65 warning applicable
- Type: Bored-to-Size Type BS
- Country of Origin: US
