Product Description
The MARS Fan Blade, MPN 40380, is designed as a replacement for various OEM applications. These heavy-duty condenser fan blades are effective and reliable. The hub is located on the intake side for most installations. It is crucial to note the original hub location for selecting the correct fan blade replacement.
- Hub location: Intake side
- Number of blades: 4
- Material: Aluminum
Product Highlights
This fan blade is suitable for HVAC systems where efficiency and functionality are essential.
Product Information
Standard Information
- MPN: 40380
- Brand: MARS
Technical Specifications
- Hub Location: Intake
- Diameter: 22 inches
- Pitch: 24 degrees
- Bore Diameter: 1/2 inches
- Rotation: CW
- Material: Aluminum
- Max RPM: 1140
- Depth: 3 55/64 inches
- CFM @ 0.000-In. SP: 4861
- CFM @ 0.300-In. SP: 4011
- Min H.P. @ 0.000-in. SP: 0.3496
- Min H.P. @ 0.300-in. SP: 0.4585
