Product Description
LEGEND VALVE presents the 104-505 1 T-415 Gate Valve, designed for water and steam applications. This valve features FNPT end styles and operates at a maximum pressure rating of 200 psi CWP. The valve’s robust construction ensures durability and reliability in various commercial and industrial settings.
- Body made of cast bronze for strength
- Handwheel actuator for easy operation
- Precision-ground integral seats ensure a leak-tight seal
Product Highlights
This product is ideal for controlling the flow of water or steam in piping systems.
Product Information
Standard Information
- Manufacturer: LEGEND VALVE
- UPC: 662545001463
Technical Specifications
- Actuator Type: Handwheel
- Body Material: Cast Bronze
- Domestic/Import: Import
- End Style: FNPT
- Hand Wheel Diameter: 2.76 inches
- Inlet to Outlet Length: 2.13 inches
- Nominal Size: 1 inch
- Pressure Class: 125 lb
- Pressure Rating: 200 psi CWP
- Series: T-415
- Softgoods Material: NBR Stem Packing
- Top to Inlet Center: 3.86 inches
- Trim Material: Brass
