Product Description
The Hubbell YS32 Butt Splice Long is a compression splice designed for stranded copper conductors up to 400 kcmil. It measures four point six two inches in length and is suitable for heavy-duty applications. This butt splice can handle voltages from six hundred to thirty-five thousand VAC.
- Ideal for 600 V heavy-duty applications
- Can handle voltages up to 35 kV
- High pull-out force for enhanced mechanical and electrical integrity
Product Highlights
The YS32 butt splice is ideal for use in demanding electrical systems, ensuring reliable connections in various applications.
Product Information
Standard Information
- Manufacturer: Hubbell
- UPC: 78181050840
Technical Specifications
- Application: For heavy-duty applications and used at higher voltages
- Barrel Size: 28 inches
- Color: Blue
- Conductor Size: 400 kcmil
- Conductor Type: Stranded Copper
- Finish: Tin Plated
- Length: 4.62 inches
- Material: Copper
- Temperature Rating: 90 degrees Celsius
- Voltage Rating: 600 to 35000 VAC
- Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 486A-486B
