Product Description
The Hubbell OLR-7 is a conduit body designed for use in electrical installations. It features a two and one-half inch hub with a capacity of one hundred forty-two cubic inches. This model is suitable for wet locations when used with gasketed covers. Constructed from copper-free aluminum, it is electrostatically powder coated for durability.
- Two hubs for effective wiring solutions.
- Interchangeable with competitor products.
- Designed for pulling, splicing, and maintenance tasks.
Product Highlights
The Hubbell OLR-7 combines reliability with effective performance across various applications in electrical systems.
Product Information
Standard Information
- Manufacturer: Hubbell
- MPN: OLR-7
Technical Specifications
- Application: For pulling, splicing, and maintenance
- Color: Gray
- Connection Type: Thread
- Dimensions: Thirteen and eleven-sixteenths inches long x five and three-fourths inches wide x four inches high
- Finish: Powder Coated
- Hub Size: Two and one-half inches
- Material: Aluminum
- Number of Hubs: Two
- Series: O Series
- Standards/Approvals: UL File No. E3397, CSA File No. LR11852, Federal Specification W-C-586D/A-A 50563, NEC 501.10(b) Class I Div 2, 502.10, 503.10
- Type: Type LR
