Product Description
Firestone W013587336 is a high temperature airstroke actuator and airmount isolator. This device is designed for industrial applications and is effective in both linear and angular motion. Air springs provide significant flexibility, making them ideal for machinery that performs pressing, lifting, or conveying tasks.
- Provides low profile actuation
- Reduces vibrations on machines
- Suitable for various industrial applications
Product Highlights
This air spring is effective for isolating vibrations and offering robust motion control in diverse industrial settings.
Product Information
Standard Information
- Brand: Firestone
- Part Number: W013587336
Technical Specifications
- Style No.: 26
- Air Inlet Type: NPT
- Max Pressure: 100 psi
- Temperature Range: 0 °F to 225 °F
- Compressed Height: 3.8 inches
- Force @ 1 in Stroke: 3437.5 lbf
- End Closure: Type 1 Bead Plate
- Air Inlet: 1/4 inches
