Product Description
The Timken VCJ1 is a flange mount ball bearing unit designed for various industrial applications. It features a one-inch diameter bore and is suitable for mounting on straight shafts. The unit comes pre-assembled and ready for quick installation. Its sturdy construction ensures reliability even under demanding conditions.
- 1-inch diameter bore for versatile applications
- Robust flange mount designed for easy installation
- Factory pre-lubricated for immediate use
Product Highlights
This unit is ideal for use in sectors such as agriculture, food processing, and material handling.
Product Information
Standard Information
- Brand: Fafnir
- Manufacturer: Timken
Technical Specifications
- MPN: VCJ1
- Series: VCJ
- Bore Diameter: 1 in
- Load Capacity: 3490 lb Dynamic / 1760 lb Static
- Maximum Speed: 5440 rpm
- Overall Depth: 1.696 in
- Overall Height: 1.696 in
- Overall Length/Diameter: 3-3/4 in
- Bolt Center-to-Center Length: 2-3/4 in
- Temperature Rating: -30 to 275 deg F
- Locking Device: Eccentric
- Bearing Material: Steel
- Flange Mounting Type: 4-Bolt
- Finish: Uncoated
