Product Description
ECM Industries PCT-4-350 is a Multi-Tap Connector designed for safe and reliable electrical connections. This Type PCT 4-Port Dual Rated Insulated connector is made for aluminum and copper conductors, rated for 600 VAC.
- Holds wire sizes from 6 AWG to 350 kcmil
- Temperature range from -45 to 90 degrees Celsius
- Fully insulated design allows for visible inspection
Product Highlights
The PCT-4-350 connector simplifies the wiring process with user-friendly access from both sides. Its design ensures high reliability without the need for taping.
Product Information
Standard Information
- Manufacturer: ECM Industries
- Part Number: PCT-4-350
Technical Specifications
- Conductor Type: Aluminum/Copper
- Dimensions: 5.06 in L x 2.69 in W x 2.65 in H
- Wire Size Range: 6 AWG to 350 kcmil
- Hex Size: 5/16 in
- Temperature Rating: -45 to 90 degrees Celsius
- Voltage Rating: 600 VAC
- Standards/Approvals: CSA File No. LR29601, UL File No. E6207/453G/486A/B
