Product Description
The Eaton CH24BPN100E is a load center designed for residential and light commercial power distribution. This product features a single-phase setup with twenty-four circuits and accommodates wire sizes from two AWG to three hundred kcmil. Rated for one hundred amperes, it operates at a voltage of one hundred twenty to two hundred forty VAC and complies with UL standards.
- Single-phase design with a capacity of one hundred amps
- Twenty-four circuits and poles for extensive distribution
- NEMA 1 enclosure suitable for indoor applications
Product Highlights
This load center is equipped with plug-on breakers and is suitable for systems needing reliable circuit protection.
Product Information
Standard Information
- Brand: Eaton
- MPN: CH24BPN100E
Technical Specifications
- Breaker Type: CH/CSH
- Amperage Rating: 100 A
- Voltage Rating: 120/240 VAC
- Number of Circuits: 24
- Number of Poles: 24
- Dimensions: 29.13 inches L x 14.31 inches W x 3.88 inches H
- Wire Size: 2/0 AWG to 300 kcmil
- Interrupt Rating: 25 kA
- Enclosure Type: NEMA 1
- Housing Material: Metal
- Mounting Type: Plug-On
