Product Description
The Chance BP3R2B is a righthand opening, 25kV, 125kV LIW 600A bypass switch designed for utility applications. This switch is built with a backstrap for enhanced functionality. It is suitable for various utility installations where reliable performance is essential.
- Rated for 25kV and 125kV applications
- Constructed from solid copper with a galvanized steel base
- Meets all applicable ANSI/IEEE standards
Product Highlights
This bypass switch is essential for ensuring safe and efficient operations in electrical distribution systems.
Product Information
Standard Information
- Manufacturer: Chance
- Vendor: 182500
Technical Specifications
- Voltage – Maximum: 29 kV
- Weight: 108 lbs
- Size: 29.250 in x 29.250 in x 22.375 in
- Blade Type: Solid Copper (two blade truss-member)
- Material – Base: Galvanized Steel per ASTM A153
- Creep and Leakage Distance: 21.9 in (556.3 mm)
- Arc Distance – Dry: 8.1 in (205.7 mm)
- Current Overload – 8hr Emergency: 1080 A
