Product Description
The Bussmann PDBFS220 is a power distribution block designed for reliable electrical connections in various applications. It operates at a voltage rating of six hundred VAC/VDC and supports a maximum current of one hundred seventy-five amps. This product features one pole, making it suitable for single pole installations. The PDBFS220 can accommodate conductor sizes from eight to two-ought AWG on the line side and twelve to four AWG on the load side.
- IP20 rated for finger-safe protection
- Capable of handling short circuit currents up to two hundred kiloamps
- Modular design allows for easy gang mounting
Product Highlights
This power distribution block provides a compact footprint with a modular capability that enhances installation efficiency. It meets UL and NEC standards for safety and performance.
Product Information
Standard Information
- Brand: Bussmann
- Manufacturer: Eaton
Technical Specifications
- Voltage Rating: 600 VAC/VDC
- Amperage Rating: 175 A
- Short Circuit Current Rating: 200/100 kA
- Material: Aluminum, Tin Plated
- Fuse Type: Class J/RK1/RK5/T
- Number of Poles: 1
- Wire Size Range: 8 to 2/0 AWG for Line, 12 to 4 AWG for Load
- Dimensions: 3.372 inches L x 1.03 inches W x 2.146 inches H
