Product Description
The Bussmann LP-CC-10 is a time delay fuse rated for 10 Amps and designed for use in various electrical applications. This fuse operates at 600 Volts AC and 150 Volts DC. It has a high interrupt rating of 200 Kilo-Amps for AC and 20 Kilo-Amps for DC, ensuring effective protection against short-circuit current overloads.
- Features a dual-element design for optimized time delay performance
- Constructed with a durable melamine body for reliable operation
- UL listed and compliant with CSA, CE, and RoHS standards
Product Highlights
The Bussmann LP-CC-10 is ideal for use in branch circuits, industrial control systems, and street lighting. Its rejection-style feature ensures compatibility with Class CC fuse blocks, making it a safe choice for circuits requiring time delay and current limitation.
Product Information
Standard Information
- Brand: Bussmann
- MPN: LP-CC-10
Technical Specifications
- Type: Rejection, Current-Limiting
- Voltage Rating: 600 Vac, 150 Vdc
- Amperage Rating: 10 Amps
- Interrupt Rating: 200 Kilo-Amp at 600 Vac, 20 Kilo-Amp at 150 Vdc
- Dimensions: 0.41 inches diameter x 1.5 inches length
- Construction: Melamine body
- Mounting: Clip
- Response Time: 12 seconds at 200% rated load
