Product Description
The Appleton CG90-6250 is a 90-degree liquidtight strain relief cord and cable connector made from cast aluminum. This connector is designed to accommodate conductors ranging from five-eighths to three-quarters of an inch in diameter. It is suitable for use in both wet and dry locations, ensuring reliable performance in various environments.
- Constructed from cast aluminum with copper-free aluminum components
- NEMA rating of 3R for moisture protection
- Designed for flexible type neoprene, hypalon, and PVC jacketed power or control cord and cable
Product Highlights
This strain relief connector features a threaded hub connection for secure fitment. The neoprene sealing grommet maintains a firm grip on cable jackets, providing strain relief while safeguarding internal wiring connections.
Product Information
Standard Information
- Manufacturer: Appleton Electric
- Catalog Number: CG90-6250
Technical Specifications
- Material: Cast aluminum
- NEMA Rating: 3R
- Conductor Range: 5/8 – 3/4 inch
- Connection: Threaded hub
- Application: Liquidtight, strain relief, dry, wet, and hazardous locations
- Size: 1/2 inch
- Approval: UL 514B, CSA C22.2
- Country of Origin: Mexico
